PE100 Hdpe Pipe Dn20mm-dn1600mm Irrigation

Name: PE100 Hdpe Pipe Dn20mm-dn1600mm Irrigation Manufacturers and Suppliers China - Customized Products Wholesale - Kangyu
Brand: KANGYU
SKU: 304771215

china manufacturer produce hdpe pipe and fittings , ppr pipe and fittings ,size from dn20mm-dn1600mm,sdr11 pn16

Send Inquiry

Chat Now

Description

shandong kangyu pipe industry co.,ltd introduce :

Shandong Kangyu Pipe Industry Co., Ltd. specializes in the manufacture of plastic pipes. Founded in 2014, the company boasts an annual output of 100,000 tons of HDPE pipes and fittings. It has newly installed 15 high-speed production lines, enabling the production of extra-thick-wall pipes ranging from 20 mm to 1600 mm in diameter with a rated pressure of 1.6 MPa, as well as high-pressure wear-resistant pipes for mining applications. The mining pipes feature diameters from 50 mm to 630 mm and can withstand working pressure up to 10.0 MPa. The company's products are sold far to markets including Australia and South America.

HDPE Plastic Polyethylene Pipe for Water supply irrigation slurry

HDPE pipe introduce

HDPE pipe is made of High density polyethylene PE100 raw materials , The Hdpe pipe inner wall is smooth, and does not change with the use of time, small friction resistance, energy saving, pressure loss is about 30% smaller than steel pipe, can choose a smaller diameter than steel pipe. Good hygienic performance, no additives, no possibility of pollution of drinking water, ISO standard grading polyethylene material is 0 (the lowest level), do not moldy material, compared with some other commonly used plastic materials, polyethylene mildew resistance is much higher, long-term use also does not scale.

HDPE PIPE Features.

1. High toughness and good seismic performance;
2. The connection is reliable;
3. Low density, light weight, easy to handle and install
4. Can resist a variety of chemical media corrosion;
5. Excellent hydraulic performance, the wear resistance coefficient is only 0.009;
6. Long service life, up to 50 years to 100 years ;
7. Good hygiene and environmental performance;
8. Better resistance to slow crack growth (SCG) and rapid crack propagation (RC

HDPE PIPE APPLICATION

HDPE water supply pipe can be used for general purpose pressure water transmission and drinking water transmission. Mining slurry transfter ,irrigations electrical cable His surface
color indicates that his use is mainly for water-related pipes (water supply pipes), gas pipes in yellow, fire-fighting pipes in
red and mining pipes.

There are mainly municipal buried water supply, building water supply (drainage), farmland irrigation, waterscape engineering and
so on. In water supply pipeline engineering, PE water supply pipe will eventually replace UPVC pipe.

The Hdpe pipe size list

Specification Parameters
Outer diameter (mm)	Standard scale ratio
	SDR26	SDR21	SDR17	SDR13.6	SDR11
	0.6Mpa	0.8Mpa	1Mpa	1.25Mpa	1.6Mpa
DN20	-	-	-	-	2.3
DN25	-	-	-	-	2.3
DN32	-	-	-	-	3.0
DN40	-	-	-	-	3.7
DN50	-	-	-	-	4.6
DN63	-	-	-	4.7	5.8
DN75	-	-	4.5	5.6	6.8
DN90	-	4.3	5.4	6.7	8.2
DN110	4.2	5.3	6.6	8.1	10.0
DN125	4.8	6.0	7.4	9.2	11.4
DN140	5.4	6.7	8.3	10.3	12.7
DN160	6.2	7.7	9.5	11.8	14.6
DN180	6.9	8.6	10.7	13.3	16.4
DN200	7.7	9.6	11.9	14.7	18.2
DN225	8.6	10.8	13.4	16.6	20.5
DN250	9.6	11.9	14.8	18.4	22.7
DN280	10.7	13.4	16.6	20.6	25.4
DN315	12.1	15.0	18.7	23.2	28.6
DN355	13.6	16.9	21.1	26.1	32.2
DN400	15.3	19.1	23.7	29.4	36.3
DN450	17.2	21.5	26.7	33.1	40.9
DN500	19.1	23.9	29.7	36.8	45.4
DN560	21.4	26.7	33.2	41.2	50.8
DN630	24.1	30.0	37.4	46.3	57.2
DN710	27.2	33.9	42.1	52.2	-
DN800	30.6	38.1	47.4	58.8	-
DN900	34.4	42.9	53.3	-	-
DN1000	38.2	47.7	59.3	-
